- Overview
- Product Description
- Product Parameters
- Packaging & Shipping
Basic Info.
Model NO.
PH62S
Maximum Load
500kg
Specification
4inch/5inch/6inch/8inch, GB
Diameter
100mm/125mm/150mm/200mm
Thickness
2in
Product Name
Solid Caster Wheel /W Roller Bearing for Material
Material
Phenolic
Bearing
Roller Bearing
Application
Dustbin Can
Size
4in/5in/6in/8in
Finishing Coating
Bright Zinc Plating
Color
White
Steel Thickness
5.5mm Steel Plate
OEM
Accept OEM
Usage
Cargo Container, Material Handling Cart
Transport Package
Plywood Box / Iron Box
Trademark
Super Star
Origin
Xiangtan
HS Code
871690
Production Capacity
30000PCS/Month
Product Description
Solid caster wheel with roller bearing for material handling
Xiangtan Superstar casters & wheels offers Medium &Heavy duty Industrial Castors & Wheels,offering load capacities from 350Kg to 5500kg.&Wheels from 100mm to 400mm diameter.
Medium Heavy duty Phenolic resin wheel casters are: Swivel caster and Rigid caster
1. Wheel material: Phenolic resion wheel
2. Wheel dia: 4in*2in, 5in*2in,6in*2in,8in*2in,
3. Wheel width: 2in
4. Housing thickness: 5.5mm steel plate
5.Top plate dimensions:100*114mm
6.Load Cspacity: 350KG-450KG
7. Brake
8.Application:Cargo Contianers, Material Handling Cart
Medium Heavy duty Phenolic resin wheel casters details:
| wheel diameter | wheel width | wheel material | load capacity | bearing type | overall height | swivel lead | swivel caster | rigid caster |
| 4in | 2in | Phenolic resin | 350lbs | roller bearing | 5-5/8in | 1-1/6in | PH42S | PH42R |
| 5in | 2in | Phenolic resin | 400lbs | roller bearing | 6-1/2in | 1-1/3in | PH52S | PH52R |
| 6in | 2in | Phenolic resin | 450lbs | roller bearing | 7-1/2in | 1-5/9in | PH62S | PH62R |
| 8in | 2in | Phenolic resin | 550lbs | roller bearing | 9-1/2in | 1-19/20in | PH82S | PH82R |
Package:
4" caster: 300pcs/crate,5" caster: 290pcs/crate
6" caster: 250pcs/crate
8" caster: 160pcs/crate
Iron crate dimensions: 970*870*880MM
24pcs crates/20'container
Delivery time:
30 days after receiving the deposit.
