5in Yellow Zinc Plate Heavy Duty Caster with Locking

Find high quality 5in Yellow Zinc Plate Heavy Duty Casters with Locking from our factory. Durable and reliable for heavy duty use. Shop now!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
P160-20F125X50S
Bearing Type
Ball Bearing
Surface Treatment
Zinc Plated
Brand
Double Rhombus
Maximum Load
550/700/800kg
Specification
5/6/8 Inch, GB; ISO, BSCI, SGS, REACH, ROHS
Diameter
125/150/200mm
Thickness
50/50/50mm
Style Name
White Nylon Heavy Duty Caster
Application
Industrial Equipment
Size
125/150/200mm
Width
50/50/50mm
Wheel Color
White
Fork Material
Pressed Steel Fork
Fork Color
Yellow
Offset
55mm
Load Capacity
550/700/800kg
Over Height
166/194.5/241mm
Transport Package
Cartons for White Nylon Heavy Duty Caster
Trademark
Double Rhombus
Origin
Hubei, China
HS Code
87169000
Production Capacity
500, 000 PCS/ Month for Caster

Product Description

Parameter

Model No. P160-20F125X50S Fixing hole size 12mm
Wheel material Nylon Bolt hole spacing 105X80mm
Wheel diameter 125mm Hole spacing 135X110X6mm
Wheel width 50mm Brake Yes
Overall height 166mm Bracket thickness 4.5mm
Offset 55mm Housing material Pressed steel housing
Load capacity 550Kg Application Industrial equipments

5in Yellow Zinc Plate Heavy Duty Caster with Locking 5in Yellow Zinc Plate Heavy Duty Caster with Locking

Heavy Duty Casters' general features:
Heavy duty caster is the new designed caster, it not only has beautiful shape but also with good load capacity when it is running.
1. Heavy duty caster: Wheel tread is nylon. And wheel size is from 125mm to 200mm.
2. Its load capacity is from 550kg to 800kg.
3. Caster fork is steel housing with yellow zinc plating.
4. Heavy duty caster: Wheel made of white nylon with double ball bearing or roller bearing or plain bearing.
5. There are two other wheels for you to choosen: 20D: White nylon, roller bearing; And 20C white nylon, plain bearing
6. There are three types caster: Fixed type caster; Swivel plate caster and swivel plate with total brake caster.
7. Δ Packing: 40pcs for one carton; 100pcs/carton for small caster and other packing ways.

Industiral Caster's introduction:
1. A caster is an undriven, single, double, or compound wheel that is designed to be mounted to the bottom of a larger object so as to enable that object to be easily moved. They are available in various sizes, industrial casters' optional size: 100mm, 125mm, 150mm, 200mm, with fixed plate, swivel top-plate with or without brake. Swivel bolt hole with or without brake.
2. The housing is made of high quality carbon steel with elegant galvanized apearance, and it suits for many kinds of industrial equipments.
3. Casters are found in numerous applications, including shopping carts, office chairs, and material handling equipment. With high load capacity, heavy duty casters are used in many industrial applications.
4. Our company can manufacturing a large number of casters, wheels, our main products are Heavy duty caster, shopping cart casters, industrial casters for European types series, casters for garbage bin series, stainless steel casters, medical casters, instrumental casters, furniture casters, twin wheel casters and medium duty casters and so on.

Double Rhombus do the best casters in China:
1. Scientific structure design;
2. Special rotation design;
3. High quality material to ensure the caster capability.
4. High quality materials purchased with strict quality checking.
5. Producing strictly according to the ISO quality management system.
6. Each product will be checked strictly before packing.
7. The most important thing is: We are professional manufacturer.

Test range:
1. Shock absorption function
2. Load capacity
3. Rotating ability
4. Impact resisting performance
5. Running ability
6. Service life evaluation

Delivery and payment:
2. The payment will be by T/T. 40% advance payment. The balance paid before shipment
3. The goods will be shipped within 4 weeks after receiving down payment from buyer.

Company information
1) Our company was founded in 1978, it has gotten certificates of ISO9001 quality system, OHSAS 18001 health system and ISO 14001circumstance system already. The National Standard Bureau entrusted our company to compile the National standard GB/T14687-93 and GB/T14688-93 for industrial caster in 1993 and 2011.

2) Our company has more than ten years export experience, professional manufacturing technology, and a strict quality control system. Most of our engineers and mechanics have more than 10 years experiences on manufacturing caster. Our factory has modern manufacturing processes, equipment and mature production lines for mould making, curved cutting, punching, welding, surface plating, machine assembling and capability tests for casters, airport trolley, airport counter, airport chair, queue stand, foldable hand truck.

3)  We have our own development and design teams. If there is any product you are interested in, please send us an inquiry, if you couldn't find what you want , please also let us know, we could make it customized for you.


Sample service


Sample         Available
Sample fee  Paid by customer, but can be refund when mass production
Delivery fee Send by express or by air, paid by customer, but can be refund after mass production


Service

Quick response: Our customers will get our reply with 24 hours, and get our quote within 24 hours during working days. You will get our best service


FAQ: Information we need to know

Model No. of  products
Quantity

5in Yellow Zinc Plate Heavy Duty Caster with Locking 5in Yellow Zinc Plate Heavy Duty Caster with Locking 5in Yellow Zinc Plate Heavy Duty Caster with Locking 5in Yellow Zinc Plate Heavy Duty Caster with Locking 5in Yellow Zinc Plate Heavy Duty Caster with Locking

***Pls contact us directly, if there are' t products that you are looking for, we will design for you specially.
Dia. Width Load capacity Over height Offset Hole size Top-plate size Bolt hole spacing Housing thickness
125mm 50mm 550kg 166mm 55mm 12mm 135x110x6 105x80 4.5mm
150mm 50mm 700kg 194.5mm 55mm 12mm 135x110x6 105x80 4.5mm
200mm 50mm 800kg 241mm 55mm 12mm 135x110x6 105x80 4.5mm
